Transparent Screen Series
Transparent Screen Series
Low brightness transparent display standard module.
Contact Us
| Product Model | GM3.2 | GM3.4 | GM3.7 | GM3.9-7.8 | GM4-8 | GM5.2 | GM7.8 | GM10.4 | GM15.6 | GM20.8 | GM31.2 |
| Pixel Pitch (H/V mm) | 3.2 | 3.4 | 3.7 | 3.9-7.8 | 4-8 | 5.2 | 7.8 | 10.4 | 15.6 | 20.8 | 31.2 |
| LED Configuration | SMD1415 | SMD1415 | SMD1415 | SMD1921 | SMD1921 | SMD1921 | SMD1921 | SMD2727 | SMD3535 | SMD3535 | SMD3535 |
| Pixel Density (dot/m²) | 92416 | 82944 | 69696 | 32768 | 30000 | 36864 | 16384 | 9216 | 4096 | 2304 | 1024 |
| Scan method | 16 scan | 16 scan | 16 scan | 7 scan | 7 scan | 8 scan | 4 scan | 2-3 scan | Static | Static | Static |
| Transparency | 35% | 40% | 50% | 60% | 62% | 50% | 60% | 70% | 75% | 80% | 88% |
| Refresh Rate | 1920-3840HZ | 4800HZ | 1920-3840Hz | ||||||||
| Module Size W×H(mm) | 500×125 | 500×83.3 | 500×83.3 | 500×125 | 500×125 | 500×125 | 500×125 | 500×125 | 500×125 | 500×125 | 500×125 |
| Module Resolution W×H(dot) | 152×38 | 144×24 | 132×22 | 128×16 | 125×15 | 96×24 | 64×16 | 48x12 | 32x8 | 24x6 | 16×4 |
| Cabinet Size W×H (mm) | 1000×1000 | 1000×1000 | 1000×1000 | 1000×1000 | 1000×1000 | 1000×1000 | 1000×1000 | 1000×1000 | 1000×1000 | 1000×1000 | 1000×1000 |
| Cabinet Resolution W×H(dot) | 304×304 | 288×288 | 264×264 | 256×128 | 250×120 | 192×192 | 128×128 | 96×96 | 64x64 | 48x48 | 32×32 |
| Cabinet Weight (kg/m²） | 8-12 | 8-25 | 8-10 | 8-10 | 8-10 | 8-25 | 8-25 | 8-10 | 8-25 | ||
| IP Rating ( front/back) | INDOOR-IP30 | INDOOR—IP30 or OUTDOOR-IP65 | INDOOR-IP30 | INDOOR-IP30 | INDOOR-IP30 | INDOOR—IP30 or OUTDOOR-IP65 | INDOOR-IP30 | INDOOR—IP30 or OUTDOOR-IP65 | |||
| Brightness (CD/m²) | 1000-5000 | 1000-2000 | |||||||||
| Viewing Angle (H/V) | 140°/140° | ||||||||||
| Viewing Distance（m） | 3 | 3 | 3 | 4 | 4 | 5 | 7 | 10 | 15 | 20 | 30 |
| Gray level | 12-16bit | ||||||||||
| Max.Power Consumption(w/m²） | 800 | 400 | |||||||||
| Ave.Power Consumption(w/m²） | 260 | 160 | |||||||||
| Environment | INDOOR | INDOOR | INDOOR | INDOOR（Optional outdoor standard） | INDOOR | INDOOR | INDOOR | INDOOR（Optional outdoor standard） | INDOOR | INDOOR（Optional outdoor standard） | |
| Control Mode | Special system for LED dispaly（4G+5G、APP、WIFI、LANcontrol） | ||||||||||
| Support Input | HDMI、DVI、DP、SDI | ||||||||||
| Operation Power | AC100~240V,50/60Hz | ||||||||||
| Operating Temperature | 0℃~50℃(work),'-20℃~60℃(store) | ||||||||||
| Operating Humidity | 10%-90%RH | ||||||||||
| Operating Life | ≥100,000 hours | ||||||||||
